scheduler_ignition_controller.cpp File Reference

#include "scheduler_ignition_controller.h"
#include "scheduledIO_ign.h"
#include "elapsed_time.h"
#include "globals.h"
#include "unit_testing.h"

Macros
#define	SET_CHANNEL_ANGLE(channel)   ignitionSchedule ##channel .channelDegrees = ((channel)-1)*interCylinderAngle;
#define	SET_IGNITION_CHANNEL(channelIdx)   setIgnitionChannel(ignitionSchedule ##channelIdx, crankAngle, dwellTime, current.schedulerCutState.ignitionChannels, channelIdx);

Functions
static int8_t	constrainAdvanceTrim (int16_t advance)
static int8_t	getIgnitionTrimmedAdvance (const config13 &page13, int8_t baseAdvance, uint8_t channelIndex)
static void	setSequentialCallbacks (uint8_t numChannels)
static void	setWastedSparkCallbacks (void)
static void	setSingleChannelCallbacks (void)
static void	set4CylinderWastedCOPCallbacks (void)
static void	set6CylinderWastedCOPCallbacks (void)
static void	set8CylinderWastedCOPCallbacks (void)
static void	setWastedCOPCallbacks (uint8_t numCylinders)
static void	setRotaryFcCallbacks (void)
static void	setRotaryFdCallbacks (void)
static void	setRotaryCallbacks (uint8_t rotaryType)
TESTABLE_STATIC void	setCallbacks (uint8_t sparkMode, uint8_t numCylinders, uint8_t rotaryMode)
TESTABLE_STATIC void	resetIgnitionSchedulers (void)
void	stopAllCoilsCharging (void)
	Utility function to stop charging all ignition coils.
static void	setOddfireScheduleAngles (const config2 &page2)
static void	setRotaryScheduleAngles (void)
static void	setEvenfireScheduleAngles (const statuses &current)
static void	initScheduleAngles (const statuses &current, const config2 &page2, const config4 &page4)
TESTABLE_STATIC uint8_t	validateSparkMode (uint8_t mode, const config2 &page2)
TESTABLE_STATIC void	validateIgnitionSetup (config2 &page2, config4 &page4, config13 &page13)
static bool	isSequential720 (const config4 &page4)
static bool	isSingle720 (const config2 &page2, const config4 &page4)
static bool	is720 (const config2 &page2, const config4 &page4)
static uint16_t	calculateMaxIgnCrankAngle (const config2 &page2, const config4 &page4)
static uint8_t	calculateMaxIgnChannels (const config2 &page2, const config4 &page4)
void	initialiseIgnitionSchedules (statuses &current, config2 &page2, config4 &page4, const config10 &page10, config13 &page13, const pinNumbers_t &pins)
	Initialise all ignition schedules.
TESTABLE_INLINE_STATIC bool	isAnyIgnScheduleRunning (void)
static bool	isSwitchableCylinderCount (const config2 &page2)
static bool	isSemiSequentialIgnition (const config2 &page2, const config4 &page4, const decoder_status_t &decoderStatus)
static bool	isFullSequentialIgnition (const config4 &page4, const decoder_status_t &decoderStatus)
TESTABLE_STATIC void	changeIgnitionToHalfSync (const config2 &page2, statuses &current)
TESTABLE_STATIC void	changeIgnitionToFullSequential (const config2 &page2, statuses &current)
TESTABLE_INLINE_STATIC void	matchIgnitionSchedulersToSyncState (const config2 &page2, const config4 &page4, statuses &current)
static int16_t	_calculateSparkAngle (const IgnitionSchedule &schedule, int8_t advance)
static int16_t	_calculateCoilChargeAngle (uint16_t dwellAngle, int16_t dischargeAngle)
TESTABLE_INLINE_STATIC void	calculateIgnitionAngles (IgnitionSchedule &schedule, uint16_t dwellAngle, int8_t advance)
TESTABLE_STATIC void	calculateIgnitionTrailingRotary (IgnitionSchedule &leading, uint16_t dwellAngle, int16_t rotarySplitDegrees, IgnitionSchedule &trailing)
static void	calculateRotaryIgnitionAngles (uint16_t dwellAngle, const statuses &current)
static void	calculateNonRotaryIgnitionAngles (const config4 &page4, const config13 &page13, uint16_t dwellAngle, const statuses &current)
	BEGIN_LTO_ALWAYS_INLINE (void) calculateIgnitionAngles(const config2 &page2
	if ((current.maxIgnOutputs==4U) &&(page4.sparkMode==IGN_MODE_ROTARY))
	if (page2.perToothIgn)
TESTABLE_INLINE_STATIC void	setIgnitionScheduleDuration (IgnitionSchedule &schedule, uint32_t delay, uint16_t duration)
TESTABLE_INLINE_STATIC uint32_t	_calculateIgnitionTimeout (const IgnitionSchedule &schedule, int16_t crankAngle)
static void	setIgnitionChannel (IgnitionSchedule &schedule, uint16_t crankAngle, uint16_t dwellDuration, byte channelMask, uint8_t channelIdx)
static uint16_t	applyFixedCrankingOverride (const statuses &current, const config4 &page4)
TESTABLE_INLINE_STATIC void	applyChannelOverDwellProtection (IgnitionSchedule &schedule, uint32_t now, uint32_t dwellLimit_uS)
static void	applyChannelOverDwellProtection (IgnitionSchedule &schedule, uint32_t dwellLimit_uS)
TESTABLE_INLINE_STATIC bool	isOverDwellActive (const config4 &page4, const statuses &current)
void	applyOverDwellProtection (const config4 &page4, const statuses &current)
	Check that no ignition channel has been charging the coil for too long.
void	startIgnitionSchedulers (void)
	Start the timers that drive schedulers
void	stopIgnitionSchedulers (void)
	Stop the timers that drive schedulers

Variables
IgnitionSchedule	ignitionSchedule1 (IGN1_COUNTER, IGN1_COMPARE)
constexpr table2D_u8_u8_8 rotarySplitTable &	configPage10
const config4 &	page4
const config4 const config13 &	page13
const config4 const config13 statuses &	current
uint16_t	dwellAngle = timeToAngle(current.dwell)
	else
const config4 uint16_t	crankAngle
uint16_t	dwellTime = current.dwell + applyFixedCrankingOverride(current, page4)

Macro Definition Documentation

SET_CHANNEL_ANGLE

#define SET_CHANNEL_ANGLE

(

channel

)

ignitionSchedule ##channel .channelDegrees = ((channel)-1)*interCylinderAngle;

SET_IGNITION_CHANNEL

#define SET_IGNITION_CHANNEL

(

channelIdx

)

setIgnitionChannel(ignitionSchedule ##channelIdx, crankAngle, dwellTime, current.schedulerCutState.ignitionChannels, channelIdx);

Function Documentation

_calculateCoilChargeAngle()

static int16_t _calculateCoilChargeAngle ( uint16_t  dwellAngle, int16_t  dischargeAngle  )

inlinestatic

_calculateIgnitionTimeout()

TESTABLE_INLINE_STATIC uint32_t _calculateIgnitionTimeout	(	const IgnitionSchedule &	schedule,
		int16_t	crankAngle
	)

_calculateSparkAngle()

static int16_t _calculateSparkAngle ( const IgnitionSchedule &  schedule, int8_t  advance  )

inlinestatic

applyChannelOverDwellProtection() [1/2]

static void applyChannelOverDwellProtection ( IgnitionSchedule &  schedule, uint32_t  dwellLimit_uS  )

static

applyChannelOverDwellProtection() [2/2]

TESTABLE_INLINE_STATIC void applyChannelOverDwellProtection	(	IgnitionSchedule &	schedule,
		uint32_t	now,
		uint32_t	dwellLimit_uS
	)

applyFixedCrankingOverride()

static uint16_t applyFixedCrankingOverride ( const statuses &  current, const config4 &  page4  )

static

applyOverDwellProtection()

void applyOverDwellProtection	(	const config4 &	page4,
		const statuses &	current
	)

Check that no ignition channel has been charging the coil for too long.

The over dwell protection system runs independently of the standard ignition schedules and monitors the time that each ignition output has been active. If the active time exceeds the tune defined amount, the output will be ended to prevent damage to coils.

Note

Must be called once per millisecond by an external timer.

BEGIN_LTO_ALWAYS_INLINE()

BEGIN_LTO_ALWAYS_INLINE

(

void

)

const &

Calculate the Ignition angles for all cylinders (based on config2::nCylinders). both start and end angles are calculated for each channel. Also the mode of ignition firing - wasted spark vs. dedicated spark per cyl. - is considered here.

calculateIgnitionAngles()

TESTABLE_INLINE_STATIC void calculateIgnitionAngles	(	IgnitionSchedule &	schedule,
		uint16_t	dwellAngle,
		int8_t	advance
	)

calculateIgnitionTrailingRotary()

TESTABLE_STATIC void calculateIgnitionTrailingRotary	(	IgnitionSchedule &	leading,
		uint16_t	dwellAngle,
		int16_t	rotarySplitDegrees,
		IgnitionSchedule &	trailing
	)

calculateMaxIgnChannels()

static uint8_t calculateMaxIgnChannels ( const config2 &  page2, const config4 &  page4  )

static

calculateMaxIgnCrankAngle()

static uint16_t calculateMaxIgnCrankAngle ( const config2 &  page2, const config4 &  page4  )

static

calculateNonRotaryIgnitionAngles()

static void calculateNonRotaryIgnitionAngles ( const config4 &  page4, const config13 &  page13, uint16_t  dwellAngle, const statuses &  current  )

inlinestatic

calculateRotaryIgnitionAngles()

static void calculateRotaryIgnitionAngles ( uint16_t  dwellAngle, const statuses &  current  )

inlinestatic

changeIgnitionToFullSequential()

TESTABLE_STATIC void changeIgnitionToFullSequential	(	const config2 &	page2,
		statuses &	current
	)

changeIgnitionToHalfSync()

TESTABLE_STATIC void changeIgnitionToHalfSync	(	const config2 &	page2,
		statuses &	current
	)

constrainAdvanceTrim()

static int8_t constrainAdvanceTrim ( int16_t  advance )

inlinestatic

getIgnitionTrimmedAdvance()

static int8_t getIgnitionTrimmedAdvance ( const config13 &  page13, int8_t  baseAdvance, uint8_t  channelIndex  )

inlinestatic

if() [1/2]

if

(

(current.maxIgnOutputs==4U) &&(page4.sparkMode==IGN_MODE_ROTARY)

)

if() [2/2]

if

(

page2.

perToothIgn

)

initialiseIgnitionSchedules()

void initialiseIgnitionSchedules	(	statuses &	current,
		config2 &	page2,
		config4 &	page4,
		const config10 &	page10,
		config13 &	page13,
		const pinNumbers_t &	pins
	)

Initialise all ignition schedules.

initScheduleAngles()

static void initScheduleAngles ( const statuses &  current, const config2 &  page2, const config4 &  page4  )

static

is720()

static bool is720 ( const config2 &  page2, const config4 &  page4  )

inlinestatic

isAnyIgnScheduleRunning()

TESTABLE_INLINE_STATIC bool isAnyIgnScheduleRunning

(

void

)

isFullSequentialIgnition()

static bool isFullSequentialIgnition ( const config4 &  page4, const decoder_status_t &  decoderStatus  )

inlinestatic

isOverDwellActive()

TESTABLE_INLINE_STATIC bool isOverDwellActive	(	const config4 &	page4,
		const statuses &	current
	)

isSemiSequentialIgnition()

static bool isSemiSequentialIgnition ( const config2 &  page2, const config4 &  page4, const decoder_status_t &  decoderStatus  )

inlinestatic

isSequential720()

static bool isSequential720 ( const config4 &  page4 )

inlinestatic

isSingle720()

static bool isSingle720 ( const config2 &  page2, const config4 &  page4  )

inlinestatic

isSwitchableCylinderCount()

static bool isSwitchableCylinderCount ( const config2 &  page2 )

inlinestatic

matchIgnitionSchedulersToSyncState()

TESTABLE_INLINE_STATIC void matchIgnitionSchedulersToSyncState	(	const config2 &	page2,
		const config4 &	page4,
		statuses &	current
	)

resetIgnitionSchedulers()

TESTABLE_STATIC void resetIgnitionSchedulers

(

void

)

set4CylinderWastedCOPCallbacks()

static void set4CylinderWastedCOPCallbacks ( void  )

static

set6CylinderWastedCOPCallbacks()

static void set6CylinderWastedCOPCallbacks ( void  )

static

set8CylinderWastedCOPCallbacks()

static void set8CylinderWastedCOPCallbacks ( void  )

static

setCallbacks()

TESTABLE_STATIC void setCallbacks	(	uint8_t	sparkMode,
		uint8_t	numCylinders,
		uint8_t	rotaryMode
	)

setEvenfireScheduleAngles()

static void setEvenfireScheduleAngles ( const statuses &  current )

static

setIgnitionChannel()

static void setIgnitionChannel ( IgnitionSchedule &  schedule, uint16_t  crankAngle, uint16_t  dwellDuration, byte  channelMask, uint8_t  channelIdx  )

inlinestatic

setIgnitionScheduleDuration()

TESTABLE_INLINE_STATIC void setIgnitionScheduleDuration	(	IgnitionSchedule &	schedule,
		uint32_t	delay,
		uint16_t	duration
	)

setOddfireScheduleAngles()

static void setOddfireScheduleAngles ( const config2 &  page2 )

static

setRotaryCallbacks()

static void setRotaryCallbacks ( uint8_t  rotaryType )

static

setRotaryFcCallbacks()

static void setRotaryFcCallbacks ( void  )

static

setRotaryFdCallbacks()

static void setRotaryFdCallbacks ( void  )

static

setRotaryScheduleAngles()

static void setRotaryScheduleAngles ( void  )

static

setSequentialCallbacks()

static void setSequentialCallbacks ( uint8_t  numChannels )

static

setSingleChannelCallbacks()

static void setSingleChannelCallbacks ( void  )

static

setWastedCOPCallbacks()

static void setWastedCOPCallbacks ( uint8_t  numCylinders )

static

setWastedSparkCallbacks()

static void setWastedSparkCallbacks ( void  )

static

startIgnitionSchedulers()

void startIgnitionSchedulers

(

void

)

Start the timers that drive schedulers

stopAllCoilsCharging()

void stopAllCoilsCharging

(

void

)

Utility function to stop charging all ignition coils.

stopIgnitionSchedulers()

void stopIgnitionSchedulers

(

void

)

Stop the timers that drive schedulers

validateIgnitionSetup()

TESTABLE_STATIC void validateIgnitionSetup	(	config2 &	page2,
		config4 &	page4,
		config13 &	page13
	)

validateSparkMode()

TESTABLE_STATIC uint8_t validateSparkMode	(	uint8_t	mode,
		const config2 &	page2
	)

Variable Documentation

configPage10

constexpr table2D_u8_u8_8 rotarySplitTable& configPage10

constexpr

crankAngle

const config4 uint16_t crankAngle

Initial value:

{
  crankAngle = ignitionLimits(crankAngle)

current

const config4 const config13 statuses& current

Initial value:

{
  matchIgnitionSchedulersToSyncState(page2, page4, current)

dwellAngle

uint16_t dwellAngle = timeToAngle(current.dwell)

dwellTime

uint16_t dwellTime = current.dwell + applyFixedCrankingOverride(current, page4)

else

else

Initial value:

{
    calculateNonRotaryIgnitionAngles(page4, page13, dwellAngle, current)

ignitionSchedule1

IgnitionSchedule ignitionSchedule1(IGN1_COUNTER, IGN1_COMPARE)	(	IGN1_COUNTER	,
		IGN1_COMPARE
	)

page13

const config4 const config13& page13

page4

const config4& page4
