config_pages.h File Reference

The tune page structs and related defines. More...

#include <stdint.h>
#include "board_definition.h"
#include "load_source.h"

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	config2
struct	config4
struct	config6
struct	config9
struct	config10
struct	cmpOperation
struct	config13
struct	config15

Macros
#define	EGO_TYPE_OFF   0U
#define	EGO_TYPE_NARROW   1U
#define	EGO_TYPE_WIDE   2U
#define	INJ_TYPE_PORT   0U
#define	INJ_TYPE_TBODY   1U
#define	INJ_PAIRED   0U
#define	INJ_SEMISEQUENTIAL   1U
#define	INJ_BANKED   2U
#define	INJ_SEQUENTIAL   3U
#define	INJ_PAIR_13_24   0U
#define	INJ_PAIR_14_23   1U
#define	IGN_MODE_WASTED   0U
#define	IGN_MODE_SINGLE   1U
#define	IGN_MODE_WASTEDCOP   2U
#define	IGN_MODE_SEQUENTIAL   3U
#define	IGN_MODE_ROTARY   4U
#define	SEC_TRIGGER_SINGLE   0U
#define	SEC_TRIGGER_4_1   1U
#define	SEC_TRIGGER_POLL   2U
#define	SEC_TRIGGER_5_3_2   3U
#define	SEC_TRIGGER_TOYOTA_3   4U
#define	ROTARY_IGN_FC   0U
#define	ROTARY_IGN_FD   1U
#define	ROTARY_IGN_RX8   2U
#define	BOOST_MODE_SIMPLE   0U
#define	BOOST_MODE_FULL   1U
#define	EN_BOOST_CONTROL_BARO   0U
#define	EN_BOOST_CONTROL_FIXED   1U
#define	WMI_MODE_SIMPLE   0U
#define	WMI_MODE_PROPORTIONAL   1U
#define	WMI_MODE_OPENLOOP   2U
#define	WMI_MODE_CLOSEDLOOP   3U
#define	HARD_CUT_FULL   0U
#define	HARD_CUT_ROLLING   1U
#define	EVEN_FIRE   0U
#define	ODD_FIRE   1U
#define	EGO_ALGORITHM_SIMPLE   0U
#define	EGO_ALGORITHM_INVALID1   1U
#define	EGO_ALGORITHM_PID   2U
#define	EGO_ALGORITHM_NONE   3U
#define	STAGING_MODE_TABLE   0U
#define	STAGING_MODE_AUTO   1U
#define	NITROUS_OFF   0U
#define	NITROUS_STAGE1   1U
#define	NITROUS_STAGE2   2U
#define	NITROUS_BOTH   3U
#define	PROTECT_CUT_OFF   0U
#define	PROTECT_CUT_IGN   1U
#define	PROTECT_CUT_FUEL   2U
#define	PROTECT_CUT_BOTH   3U
#define	PROTECT_IO_ERROR   7U
#define	AE_MODE_TPS   0U
#define	AE_MODE_MAP   1U
#define	AE_MODE_MULTIPLIER   0U
#define	AE_MODE_ADDER   1U
#define	KNOCK_MODE_OFF   0U
#define	KNOCK_MODE_DIGITAL   1U
#define	KNOCK_MODE_ANALOG   2U
#define	KNOCK_TRIGGER_HIGH   0U
#define	KNOCK_TRIGGER_LOW   1U
#define	FUEL2_MODE_OFF   0U
#define	FUEL2_MODE_MULTIPLY   1U
#define	FUEL2_MODE_ADD   2U
#define	FUEL2_MODE_CONDITIONAL_SWITCH   3U
#define	FUEL2_MODE_INPUT_SWITCH   4U
#define	SPARK2_MODE_OFF   0U
#define	SPARK2_MODE_MULTIPLY   1U
#define	SPARK2_MODE_ADD   2U
#define	SPARK2_MODE_CONDITIONAL_SWITCH   3U
#define	SPARK2_MODE_INPUT_SWITCH   4U
#define	FUEL2_CONDITION_RPM   0U
#define	FUEL2_CONDITION_MAP   1U
#define	FUEL2_CONDITION_TPS   2U
#define	FUEL2_CONDITION_ETH   3U
#define	SPARK2_CONDITION_RPM   0U
#define	SPARK2_CONDITION_MAP   1U
#define	SPARK2_CONDITION_TPS   2U
#define	SPARK2_CONDITION_ETH   3U
#define	RESET_CONTROL_DISABLED   0U
#define	RESET_CONTROL_PREVENT_WHEN_RUNNING   1U
#define	RESET_CONTROL_PREVENT_ALWAYS   2U
#define	RESET_CONTROL_SERIAL_COMMAND   3U
#define	OPEN_LOOP_BOOST   0U
#define	CLOSED_LOOP_BOOST   1U
#define	SOFT_LIMIT_FIXED   0U
#define	SOFT_LIMIT_RELATIVE   1U
#define	VVT_MODE_ONOFF   0U
#define	VVT_MODE_OPEN_LOOP   1U
#define	VVT_MODE_CLOSED_LOOP   2U
#define	VVT_LOAD_MAP   0U
#define	VVT_LOAD_TPS   1U
#define	MULTIPLY_MAP_MODE_OFF   0U
#define	MULTIPLY_MAP_MODE_BARO   1U
#define	MULTIPLY_MAP_MODE_100   2U
#define	FOUR_STROKE   0U
#define	TWO_STROKE   1U
#define	GOING_LOW   0U
#define	GOING_HIGH   1U
#define	BATTV_COR_MODE_WHOLE   0U
#define	BATTV_COR_MODE_OPENTIME   1U
#define	IDLEADVANCE_MODE_OFF   0U
#define	IDLEADVANCE_MODE_ADDED   1U
#define	IDLEADVANCE_MODE_SWITCHED   2U
#define	IDLEADVANCE_ALGO_TPS   0U
#define	IDLEADVANCE_ALGO_CTPS   1U

Typedefs
using	byte = uint8_t

Enumerations
enum	MAPSamplingMethod { MAPSamplingInstantaneous = 0 , MAPSamplingCycleAverage = 1 , MAPSamplingCycleMinimum = 2 , MAPSamplingIgnitionEventAverage = 3 }

Detailed Description

The tune page structs and related defines.

Warning

The structs in this file must match the page layouts defined in the INI file.

Macro Definition Documentation

AE_MODE_ADDER

#define AE_MODE_ADDER   1U

AE_MODE_MAP

#define AE_MODE_MAP   1U

AE_MODE_MULTIPLIER

#define AE_MODE_MULTIPLIER   0U

AE_MODE_TPS

#define AE_MODE_TPS   0U

BATTV_COR_MODE_OPENTIME

#define BATTV_COR_MODE_OPENTIME   1U

BATTV_COR_MODE_WHOLE

#define BATTV_COR_MODE_WHOLE   0U

BOOST_MODE_FULL

#define BOOST_MODE_FULL   1U

BOOST_MODE_SIMPLE

#define BOOST_MODE_SIMPLE   0U

CLOSED_LOOP_BOOST

#define CLOSED_LOOP_BOOST   1U

EGO_ALGORITHM_INVALID1

#define EGO_ALGORITHM_INVALID1   1U

EGO_ALGORITHM_NONE

#define EGO_ALGORITHM_NONE   3U

EGO_ALGORITHM_PID

#define EGO_ALGORITHM_PID   2U

EGO_ALGORITHM_SIMPLE

#define EGO_ALGORITHM_SIMPLE   0U

EGO_TYPE_NARROW

#define EGO_TYPE_NARROW   1U

EGO_TYPE_OFF

#define EGO_TYPE_OFF   0U

EGO_TYPE_WIDE

#define EGO_TYPE_WIDE   2U

EN_BOOST_CONTROL_BARO

#define EN_BOOST_CONTROL_BARO   0U

EN_BOOST_CONTROL_FIXED

#define EN_BOOST_CONTROL_FIXED   1U

EVEN_FIRE

#define EVEN_FIRE   0U

FOUR_STROKE

#define FOUR_STROKE   0U

FUEL2_CONDITION_ETH

#define FUEL2_CONDITION_ETH   3U

FUEL2_CONDITION_MAP

#define FUEL2_CONDITION_MAP   1U

FUEL2_CONDITION_RPM

#define FUEL2_CONDITION_RPM   0U

FUEL2_CONDITION_TPS

#define FUEL2_CONDITION_TPS   2U

FUEL2_MODE_ADD

#define FUEL2_MODE_ADD   2U

FUEL2_MODE_CONDITIONAL_SWITCH

#define FUEL2_MODE_CONDITIONAL_SWITCH   3U

FUEL2_MODE_INPUT_SWITCH

#define FUEL2_MODE_INPUT_SWITCH   4U

FUEL2_MODE_MULTIPLY

#define FUEL2_MODE_MULTIPLY   1U

FUEL2_MODE_OFF

#define FUEL2_MODE_OFF   0U

GOING_HIGH

#define GOING_HIGH   1U

GOING_LOW

#define GOING_LOW   0U

HARD_CUT_FULL

#define HARD_CUT_FULL   0U

HARD_CUT_ROLLING

#define HARD_CUT_ROLLING   1U

IDLEADVANCE_ALGO_CTPS

#define IDLEADVANCE_ALGO_CTPS   1U

IDLEADVANCE_ALGO_TPS

#define IDLEADVANCE_ALGO_TPS   0U

IDLEADVANCE_MODE_ADDED

#define IDLEADVANCE_MODE_ADDED   1U

IDLEADVANCE_MODE_OFF

#define IDLEADVANCE_MODE_OFF   0U

IDLEADVANCE_MODE_SWITCHED

#define IDLEADVANCE_MODE_SWITCHED   2U

IGN_MODE_ROTARY

#define IGN_MODE_ROTARY   4U

IGN_MODE_SEQUENTIAL

#define IGN_MODE_SEQUENTIAL   3U

IGN_MODE_SINGLE

#define IGN_MODE_SINGLE   1U

IGN_MODE_WASTED

#define IGN_MODE_WASTED   0U

IGN_MODE_WASTEDCOP

#define IGN_MODE_WASTEDCOP   2U

INJ_BANKED

#define INJ_BANKED   2U

INJ_PAIR_13_24

#define INJ_PAIR_13_24   0U

INJ_PAIR_14_23

#define INJ_PAIR_14_23   1U

INJ_PAIRED

#define INJ_PAIRED   0U

INJ_SEMISEQUENTIAL

#define INJ_SEMISEQUENTIAL   1U

INJ_SEQUENTIAL

#define INJ_SEQUENTIAL   3U

INJ_TYPE_PORT

#define INJ_TYPE_PORT   0U

INJ_TYPE_TBODY

#define INJ_TYPE_TBODY   1U

KNOCK_MODE_ANALOG

#define KNOCK_MODE_ANALOG   2U

KNOCK_MODE_DIGITAL

#define KNOCK_MODE_DIGITAL   1U

KNOCK_MODE_OFF

#define KNOCK_MODE_OFF   0U

KNOCK_TRIGGER_HIGH

#define KNOCK_TRIGGER_HIGH   0U

KNOCK_TRIGGER_LOW

#define KNOCK_TRIGGER_LOW   1U

MULTIPLY_MAP_MODE_100

#define MULTIPLY_MAP_MODE_100   2U

MULTIPLY_MAP_MODE_BARO

#define MULTIPLY_MAP_MODE_BARO   1U

MULTIPLY_MAP_MODE_OFF

#define MULTIPLY_MAP_MODE_OFF   0U

NITROUS_BOTH

#define NITROUS_BOTH   3U

NITROUS_OFF

#define NITROUS_OFF   0U

NITROUS_STAGE1

#define NITROUS_STAGE1   1U

NITROUS_STAGE2

#define NITROUS_STAGE2   2U

ODD_FIRE

#define ODD_FIRE   1U

OPEN_LOOP_BOOST

#define OPEN_LOOP_BOOST   0U

PROTECT_CUT_BOTH

#define PROTECT_CUT_BOTH   3U

PROTECT_CUT_FUEL

#define PROTECT_CUT_FUEL   2U

PROTECT_CUT_IGN

#define PROTECT_CUT_IGN   1U

PROTECT_CUT_OFF

#define PROTECT_CUT_OFF   0U

PROTECT_IO_ERROR

#define PROTECT_IO_ERROR   7U

RESET_CONTROL_DISABLED

#define RESET_CONTROL_DISABLED   0U

RESET_CONTROL_PREVENT_ALWAYS

#define RESET_CONTROL_PREVENT_ALWAYS   2U

RESET_CONTROL_PREVENT_WHEN_RUNNING

#define RESET_CONTROL_PREVENT_WHEN_RUNNING   1U

RESET_CONTROL_SERIAL_COMMAND

#define RESET_CONTROL_SERIAL_COMMAND   3U

ROTARY_IGN_FC

#define ROTARY_IGN_FC   0U

ROTARY_IGN_FD

#define ROTARY_IGN_FD   1U

ROTARY_IGN_RX8

#define ROTARY_IGN_RX8   2U

SEC_TRIGGER_4_1

#define SEC_TRIGGER_4_1   1U

SEC_TRIGGER_5_3_2

#define SEC_TRIGGER_5_3_2   3U

SEC_TRIGGER_POLL

#define SEC_TRIGGER_POLL   2U

SEC_TRIGGER_SINGLE

#define SEC_TRIGGER_SINGLE   0U

SEC_TRIGGER_TOYOTA_3

#define SEC_TRIGGER_TOYOTA_3   4U

SOFT_LIMIT_FIXED

#define SOFT_LIMIT_FIXED   0U

SOFT_LIMIT_RELATIVE

#define SOFT_LIMIT_RELATIVE   1U

SPARK2_CONDITION_ETH

#define SPARK2_CONDITION_ETH   3U

SPARK2_CONDITION_MAP

#define SPARK2_CONDITION_MAP   1U

SPARK2_CONDITION_RPM

#define SPARK2_CONDITION_RPM   0U

SPARK2_CONDITION_TPS

#define SPARK2_CONDITION_TPS   2U

SPARK2_MODE_ADD

#define SPARK2_MODE_ADD   2U

SPARK2_MODE_CONDITIONAL_SWITCH

#define SPARK2_MODE_CONDITIONAL_SWITCH   3U

SPARK2_MODE_INPUT_SWITCH

#define SPARK2_MODE_INPUT_SWITCH   4U

SPARK2_MODE_MULTIPLY

#define SPARK2_MODE_MULTIPLY   1U

SPARK2_MODE_OFF

#define SPARK2_MODE_OFF   0U

STAGING_MODE_AUTO

#define STAGING_MODE_AUTO   1U

STAGING_MODE_TABLE

#define STAGING_MODE_TABLE   0U

TWO_STROKE

#define TWO_STROKE   1U

VVT_LOAD_MAP

#define VVT_LOAD_MAP   0U

VVT_LOAD_TPS

#define VVT_LOAD_TPS   1U

VVT_MODE_CLOSED_LOOP

#define VVT_MODE_CLOSED_LOOP   2U

VVT_MODE_ONOFF

#define VVT_MODE_ONOFF   0U

VVT_MODE_OPEN_LOOP

#define VVT_MODE_OPEN_LOOP   1U

WMI_MODE_CLOSEDLOOP

#define WMI_MODE_CLOSEDLOOP   3U

WMI_MODE_OPENLOOP

#define WMI_MODE_OPENLOOP   2U

WMI_MODE_PROPORTIONAL

#define WMI_MODE_PROPORTIONAL   1U

WMI_MODE_SIMPLE

#define WMI_MODE_SIMPLE   0U

Typedef Documentation

byte

using byte = uint8_t

Enumeration Type Documentation

MAPSamplingMethod

enum MAPSamplingMethod

Enumerator
MAPSamplingInstantaneous
MAPSamplingCycleAverage
MAPSamplingCycleMinimum
MAPSamplingIgnitionEventAverage
