decoder_t.h File Reference

#include <stdint.h>
#include <Arduino.h>

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	interrupt_t
	This structure represents a trigger interrupt. More...
struct	decoder_status_t
	Current decoder status. More...
struct	decoder_features_t
struct	decoder_t
	This structure represents a decoder configuration. More...

Enumerations
enum class	SyncStatus : uint8_t { None , Partial , Full }
	The decoder trigger status. More...

Variables
static constexpr uint8_t	TRIGGER_EDGE_NONE = 99
	This constant represents no trigger edge.

Enumeration Type Documentation

SyncStatus

enum class SyncStatus : uint8_t

strong

The decoder trigger status.

Enumerator
None	No trigger pulses are being received. Either loss of sync or engine has stopped
Partial	Primary & secondary triggers are configured, but we are only receiving pulses from the primary. Not a valid state if no secondary trigger is configured
Full	We are receiving pulses from both primary & secondary (where specified) triggers

Variable Documentation

TRIGGER_EDGE_NONE

constexpr uint8_t TRIGGER_EDGE_NONE = 99

staticconstexpr

This constant represents no trigger edge.
