board_stm32_official.h File Reference

#include <Arduino.h>
#include <HardwareTimer.h>
#include <HardwareSerial.h>
#include "STM32RTC.h"
#include <SPI.h>
#include "stm32f4xx_ll_tim.h"
#include <EEPROM_LIB_H>

Go to the source code of this file.

Macros
#define	CORE_STM32
#define	COMPARE_TYPE   uint16_t
#define	SERIAL_BUFFER_SIZE   517
#define	FPU_MAX_SIZE   32
#define	TIMER_RESOLUTION   4
#define	word(h, l)   (((h) << 8) | (l))
#define	BOARD_MAX_DIGITAL_PINS   NUM_DIGITAL_PINS
#define	BOARD_MAX_IO_PINS   NUM_DIGITAL_PINS
#define	pinIsReserved(pin)   ( ((pin) == PA11) || ((pin) == PA12) || ((pin) == PB3) || ((pin) == PB4) || ((pin) == PB5) || ((pin) == PB0) )
#define	PWM_FAN_AVAILABLE
#define	BOARD_MAX_ADC_PINS   NUM_ANALOG_INPUTS-1
#define	LED_BUILTIN   PA7
#define	EEPROM_LIB_H   "src/SPIAsEEPROM/SPIAsEEPROM.h"
#define	RTC_LIB_H   "STM32RTC.h"
#define	MAX_TIMER_PERIOD   262140UL
#define	uS_TO_TIMER_COMPARE(uS1)   ((uS1) >> 2)
#define	INJ_CHANNELS   4
#define	IGN_CHANNELS   5
#define	FUEL1_COUNTER   (TIM3)->CNT
#define	FUEL2_COUNTER   (TIM3)->CNT
#define	FUEL3_COUNTER   (TIM3)->CNT
#define	FUEL4_COUNTER   (TIM3)->CNT
#define	FUEL1_COMPARE   (TIM3)->CCR1
#define	FUEL2_COMPARE   (TIM3)->CCR2
#define	FUEL3_COMPARE   (TIM3)->CCR3
#define	FUEL4_COMPARE   (TIM3)->CCR4
#define	IGN1_COUNTER   (TIM2)->CNT
#define	IGN2_COUNTER   (TIM2)->CNT
#define	IGN3_COUNTER   (TIM2)->CNT
#define	IGN4_COUNTER   (TIM2)->CNT
#define	IGN1_COMPARE   (TIM2)->CCR1
#define	IGN2_COMPARE   (TIM2)->CCR2
#define	IGN3_COMPARE   (TIM2)->CCR3
#define	IGN4_COMPARE   (TIM2)->CCR4
#define	FUEL5_COUNTER   (TIM5)->CNT
#define	FUEL6_COUNTER   (TIM5)->CNT
#define	FUEL7_COUNTER   (TIM5)->CNT
#define	FUEL8_COUNTER   (TIM5)->CNT
#define	FUEL5_COMPARE   (TIM5)->CCR1
#define	FUEL6_COMPARE   (TIM5)->CCR2
#define	FUEL7_COMPARE   (TIM5)->CCR3
#define	FUEL8_COMPARE   (TIM5)->CCR4
#define	IGN5_COUNTER   (TIM4)->CNT
#define	IGN6_COUNTER   (TIM4)->CNT
#define	IGN7_COUNTER   (TIM4)->CNT
#define	IGN8_COUNTER   (TIM4)->CNT
#define	IGN5_COMPARE   (TIM4)->CCR1
#define	IGN6_COMPARE   (TIM4)->CCR2
#define	IGN7_COMPARE   (TIM4)->CCR3
#define	IGN8_COMPARE   (TIM4)->CCR4
#define	ENABLE_BOOST_TIMER()   (TIM1)->SR = ~TIM_FLAG_CC2; (TIM1)->DIER |= TIM_DIER_CC2IE; (TIM1)->CR1 |= TIM_CR1_CEN;
#define	DISABLE_BOOST_TIMER()   (TIM1)->DIER &= ~TIM_DIER_CC2IE
#define	ENABLE_VVT_TIMER()   (TIM1)->SR = ~TIM_FLAG_CC3; (TIM1)->DIER |= TIM_DIER_CC3IE; (TIM1)->CR1 |= TIM_CR1_CEN;
#define	DISABLE_VVT_TIMER()   (TIM1)->DIER &= ~TIM_DIER_CC3IE
#define	ENABLE_FAN_TIMER()   (TIM1)->SR = ~TIM_FLAG_CC1; (TIM1)->DIER |= TIM_DIER_CC1IE; (TIM1)->CR1 |= TIM_CR1_CEN;
#define	DISABLE_FAN_TIMER()   (TIM1)->DIER &= ~TIM_DIER_CC1IE
#define	BOOST_TIMER_COMPARE   (TIM1)->CCR2
#define	BOOST_TIMER_COUNTER   (TIM1)->CNT
#define	VVT_TIMER_COMPARE   (TIM1)->CCR3
#define	VVT_TIMER_COUNTER   (TIM1)->CNT
#define	FAN_TIMER_COMPARE   (TIM1)->CCR1
#define	FAN_TIMER_COUNTER   (TIM1)->CNT
#define	IDLE_COUNTER   (TIM1)->CNT
#define	IDLE_COMPARE   (TIM1)->CCR4
#define	IDLE_TIMER_ENABLE()   (TIM1)->SR = ~TIM_FLAG_CC4; (TIM1)->DIER |= TIM_DIER_CC4IE; (TIM1)->CR1 |= TIM_CR1_CEN;
#define	IDLE_TIMER_DISABLE()   (TIM1)->DIER &= ~TIM_DIER_CC4IE
#define	SECONDARY_SERIAL_T   HardwareSerial

Typedefs
typedef uint16_t	eeprom_address_t

Functions
char *	sbrk (int incr)
uint32_t	digitalPinToInterrupt (uint32_t Interrupt_pin)
static void	FUEL1_TIMER_ENABLE (void)
static void	FUEL2_TIMER_ENABLE (void)
static void	FUEL3_TIMER_ENABLE (void)
static void	FUEL4_TIMER_ENABLE (void)
static void	FUEL1_TIMER_DISABLE (void)
static void	FUEL2_TIMER_DISABLE (void)
static void	FUEL3_TIMER_DISABLE (void)
static void	FUEL4_TIMER_DISABLE (void)
static void	IGN1_TIMER_ENABLE (void)
static void	IGN2_TIMER_ENABLE (void)
static void	IGN3_TIMER_ENABLE (void)
static void	IGN4_TIMER_ENABLE (void)
static void	IGN1_TIMER_DISABLE (void)
static void	IGN2_TIMER_DISABLE (void)
static void	IGN3_TIMER_DISABLE (void)
static void	IGN4_TIMER_DISABLE (void)
static void	FUEL5_TIMER_ENABLE (void)
static void	FUEL6_TIMER_ENABLE (void)
static void	FUEL7_TIMER_ENABLE (void)
static void	FUEL8_TIMER_ENABLE (void)
static void	FUEL5_TIMER_DISABLE (void)
static void	FUEL6_TIMER_DISABLE (void)
static void	FUEL7_TIMER_DISABLE (void)
static void	FUEL8_TIMER_DISABLE (void)
static void	IGN5_TIMER_ENABLE (void)
static void	IGN6_TIMER_ENABLE (void)
static void	IGN7_TIMER_ENABLE (void)
static void	IGN8_TIMER_ENABLE (void)
static void	IGN5_TIMER_DISABLE (void)
static void	IGN6_TIMER_DISABLE (void)
static void	IGN7_TIMER_DISABLE (void)
static void	IGN8_TIMER_DISABLE (void)

Variables
STM32RTC &	rtc
InternalSTM32F4_EEPROM_Class	EEPROM

Macro Definition Documentation

BOARD_MAX_ADC_PINS

#define BOARD_MAX_ADC_PINS   NUM_ANALOG_INPUTS-1

BOARD_MAX_DIGITAL_PINS

#define BOARD_MAX_DIGITAL_PINS   NUM_DIGITAL_PINS

BOARD_MAX_IO_PINS

#define BOARD_MAX_IO_PINS   NUM_DIGITAL_PINS

BOOST_TIMER_COMPARE

#define BOOST_TIMER_COMPARE   (TIM1)->CCR2

BOOST_TIMER_COUNTER

#define BOOST_TIMER_COUNTER   (TIM1)->CNT

COMPARE_TYPE

#define COMPARE_TYPE   uint16_t

CORE_STM32

#define CORE_STM32

DO NOT INCLUDE DIRECTLY - should be included via board_definition.h

DISABLE_BOOST_TIMER

#define DISABLE_BOOST_TIMER

(

)

(TIM1)->DIER &= ~TIM_DIER_CC2IE

DISABLE_FAN_TIMER

#define DISABLE_FAN_TIMER

(

)

(TIM1)->DIER &= ~TIM_DIER_CC1IE

DISABLE_VVT_TIMER

#define DISABLE_VVT_TIMER

(

)

(TIM1)->DIER &= ~TIM_DIER_CC3IE

EEPROM_LIB_H

#define EEPROM_LIB_H   "src/SPIAsEEPROM/SPIAsEEPROM.h"

ENABLE_BOOST_TIMER

#define ENABLE_BOOST_TIMER

(

)

(TIM1)->SR = ~TIM_FLAG_CC2; (TIM1)->DIER |= TIM_DIER_CC2IE; (TIM1)->CR1 |= TIM_CR1_CEN;

ENABLE_FAN_TIMER

#define ENABLE_FAN_TIMER

(

)

(TIM1)->SR = ~TIM_FLAG_CC1; (TIM1)->DIER |= TIM_DIER_CC1IE; (TIM1)->CR1 |= TIM_CR1_CEN;

ENABLE_VVT_TIMER

#define ENABLE_VVT_TIMER

(

)

(TIM1)->SR = ~TIM_FLAG_CC3; (TIM1)->DIER |= TIM_DIER_CC3IE; (TIM1)->CR1 |= TIM_CR1_CEN;

FAN_TIMER_COMPARE

#define FAN_TIMER_COMPARE   (TIM1)->CCR1

FAN_TIMER_COUNTER

#define FAN_TIMER_COUNTER   (TIM1)->CNT

FPU_MAX_SIZE

#define FPU_MAX_SIZE   32

FUEL1_COMPARE

#define FUEL1_COMPARE   (TIM3)->CCR1

FUEL1_COUNTER

#define FUEL1_COUNTER   (TIM3)->CNT

FUEL2_COMPARE

#define FUEL2_COMPARE   (TIM3)->CCR2

FUEL2_COUNTER

#define FUEL2_COUNTER   (TIM3)->CNT

FUEL3_COMPARE

#define FUEL3_COMPARE   (TIM3)->CCR3

FUEL3_COUNTER

#define FUEL3_COUNTER   (TIM3)->CNT

FUEL4_COMPARE

#define FUEL4_COMPARE   (TIM3)->CCR4

FUEL4_COUNTER

#define FUEL4_COUNTER   (TIM3)->CNT

FUEL5_COMPARE

#define FUEL5_COMPARE   (TIM5)->CCR1

FUEL5_COUNTER

#define FUEL5_COUNTER   (TIM5)->CNT

FUEL6_COMPARE

#define FUEL6_COMPARE   (TIM5)->CCR2

FUEL6_COUNTER

#define FUEL6_COUNTER   (TIM5)->CNT

FUEL7_COMPARE

#define FUEL7_COMPARE   (TIM5)->CCR3

FUEL7_COUNTER

#define FUEL7_COUNTER   (TIM5)->CNT

FUEL8_COMPARE

#define FUEL8_COMPARE   (TIM5)->CCR4

FUEL8_COUNTER

#define FUEL8_COUNTER   (TIM5)->CNT

IDLE_COMPARE

#define IDLE_COMPARE   (TIM1)->CCR4

IDLE_COUNTER

#define IDLE_COUNTER   (TIM1)->CNT

IDLE_TIMER_DISABLE

#define IDLE_TIMER_DISABLE

(

)

(TIM1)->DIER &= ~TIM_DIER_CC4IE

IDLE_TIMER_ENABLE

#define IDLE_TIMER_ENABLE

(

)

(TIM1)->SR = ~TIM_FLAG_CC4; (TIM1)->DIER |= TIM_DIER_CC4IE; (TIM1)->CR1 |= TIM_CR1_CEN;

IGN1_COMPARE

#define IGN1_COMPARE   (TIM2)->CCR1

IGN1_COUNTER

#define IGN1_COUNTER   (TIM2)->CNT

IGN2_COMPARE

#define IGN2_COMPARE   (TIM2)->CCR2

IGN2_COUNTER

#define IGN2_COUNTER   (TIM2)->CNT

IGN3_COMPARE

#define IGN3_COMPARE   (TIM2)->CCR3

IGN3_COUNTER

#define IGN3_COUNTER   (TIM2)->CNT

IGN4_COMPARE

#define IGN4_COMPARE   (TIM2)->CCR4

IGN4_COUNTER

#define IGN4_COUNTER   (TIM2)->CNT

IGN5_COMPARE

#define IGN5_COMPARE   (TIM4)->CCR1

IGN5_COUNTER

#define IGN5_COUNTER   (TIM4)->CNT

IGN6_COMPARE

#define IGN6_COMPARE   (TIM4)->CCR2

IGN6_COUNTER

#define IGN6_COUNTER   (TIM4)->CNT

IGN7_COMPARE

#define IGN7_COMPARE   (TIM4)->CCR3

IGN7_COUNTER

#define IGN7_COUNTER   (TIM4)->CNT

IGN8_COMPARE

#define IGN8_COMPARE   (TIM4)->CCR4

IGN8_COUNTER

#define IGN8_COUNTER   (TIM4)->CNT

IGN_CHANNELS

#define IGN_CHANNELS   5

INJ_CHANNELS

#define INJ_CHANNELS   4

LED_BUILTIN

#define LED_BUILTIN   PA7

MAX_TIMER_PERIOD

#define MAX_TIMER_PERIOD   262140UL

pinIsReserved

#define pinIsReserved

(

pin

)

( ((pin) == PA11) || ((pin) == PA12) || ((pin) == PB3) || ((pin) == PB4) || ((pin) == PB5) || ((pin) == PB0) )

PWM_FAN_AVAILABLE

#define PWM_FAN_AVAILABLE

RTC_LIB_H

#define RTC_LIB_H   "STM32RTC.h"

SECONDARY_SERIAL_T

#define SECONDARY_SERIAL_T   HardwareSerial

SERIAL_BUFFER_SIZE

#define SERIAL_BUFFER_SIZE   517

TIMER_RESOLUTION

#define TIMER_RESOLUTION   4

uS_TO_TIMER_COMPARE

#define uS_TO_TIMER_COMPARE

(

uS1

)

((uS1) >> 2)

VVT_TIMER_COMPARE

#define VVT_TIMER_COMPARE   (TIM1)->CCR3

VVT_TIMER_COUNTER

#define VVT_TIMER_COUNTER   (TIM1)->CNT

word

#define word	(		h,
			l
	)		(((h) << 8) | (l))

Typedef Documentation

eeprom_address_t

typedef uint16_t eeprom_address_t

Function Documentation

digitalPinToInterrupt()

uint32_t digitalPinToInterrupt ( uint32_t  Interrupt_pin )

inline

Here is the call graph for this function:

Here is the caller graph for this function:
